Basic Network TWAIN Scanner Operation
105
5
Basic Network TWAIN Scanner Operation
This section describes the basic operation for scanning with the network TWAIN
scanner.
Important
❒ To use the network TWAIN scanner, a TWAIN-compliant application, such
as DeskTopBinder and the TWAIN driver must be installed on the client com-
puter.
The following example procedure uses Windows XP and DeskTopBinder Lite.
A On the [Start] menu, point to [All Programs], point to [DeskTopBinder], and then
click [DeskTopBinder].
B On the [Tools] menu, click [Scanner Settings...].
C Click [Select Scanner Driver...].
D Select the name of the machine you want to use in the list, and then click
[Select].
E Click [OK].
F On the [File] menu, point to [Add Document], and then click [Scan...] to display
the Scanner Control dialog box.
A dialog box that is used to control a scanner using the TWAIN driver is re-
ferred to as the Scanner Control dialog box.
G Make settings according to such factors as the type of original, type of scan-
ning, and orientation of the original.
For details, see the TWAIN driver Help.
H In the Scanner Control dialog box, click [Scan].
Depending on the security setting, if you press [Scan], a dialog box for enter-
ing the user name and password may appear.
I Place originals, and then start scanning.
If you have more originals to scan, place the next original.
J If you complete scanning, click [Cancel] on the computer.
K On the [File] menu, click [Exit].
L Enter the file name, and then click [OK].
The DeskTopBinder Viewer closes and the image is stored in DeskTopBinder
Lite.
