To watch a DVD image, select “INPUT1” using
TV/VIDEO on the remote control unit or TV/
VIDEO on the TV.
1
Displaying a DVD image (Example)
INPUT SOURCE
TV
DTV
INPUT1
INPUT2
INPUT3
INPUT4
INPUT5
Select the desired signal type on “Input Select”
in the “Option” menu.
2
MENU
[
Option
...
Input Select
]
Auto
COMPONENT
VIDEO
For INPUT1 signal
The setting is stored and can be selected.
NOTE
• Each time TV/VIDEO is pressed, the input source toggles.
• If the image does not come in clearly, you may need to
change the input signal type setting on the “Input Select”
menu.
• Refer to your external equipment operation manual for the
signal type.
Displaying an external equipment
Explanation here is for the setting when connecting
DVD player to INPUT1 terminal.
Using external equipment
Input Select
Selecting input source
Can use for selecting the input source.
Using TV/VIDEO on the remote control unit or on
the TV
TV/VIDEO allows you to choose from the available
input sources.
Press TV/VIDEO on the remote control unit or
on the TV to select the input source.
• The image from the selected source automatically
displays.
• You can also select the input source by pressing
a
/
b
.
2
Press TV/VIDEO on the remote control unit or
on the TV.
1
Press MENU and the MENU screen displays.
1
Press
c
/
d
to select “Option”.
2
Press
a
/
b
to select “Input Select”, and then
press ENTER.
3
Selecting input signal type
For setting the signal type of external equipment.
Press
a
/
b
to select a signal type you want to
set, and then press ENTER.
4
NOTE
• If no (colour) image displays, try to change the other
signal type.
• Check the operation manual of the external equipment for
the signal type.
• When the signal type is set to “Auto”, the input terminal
where cable is connected is automatically selected.
• When the signal type is set to “Auto” and multiple video
signal cables are connected, the signal type is selected in
the following prioritised order:
INPUT 1/INPUT 2: COMPONENT
s
VIDEO
• When the signal type for “INPUT5” is set to “DIGITAL”
or “ANALOGUE”, a “PC” or “AV” signal is automatically
detected.
Input source
INPUT 1
INPUT 2
INPUT 5
Selectable item
Auto, COMPONENT, VIDEO
Auto, COMPONENT, VIDEO
Auto, DIGITAL, ANALOGUE
49
