Product Quick Specs:
ENGINE:
27 HP* Kohler
Make Kohler
Model CV740S
Horsepower 27 @ 3600 rpm
Displacement 44.24 Cu. in (725 cc)
Electrical System 12 Volt, 16 amp. Alternator, Battery: 340
CCA
Oil Capacity 4.2 pt. (2.0 L) w/ Filter
CHASSIS:
Fuel Tank Capacity: 11 Gallons (41.6 L) Total
Rear Wheels Tire Size: 22 x 11.00 -10
Inflation Pressure: 15 psi (1,03 bar)
Front Wheels Tire Size: 13 x 5.00 - 6
Inflation Pressure: 25 psi (1,72 bar)
TRANSMISSIONS:
HydroGear PG-3H / HGM-12E 3131
Type Pump and Wheel Motor
Hydraulic Fluid Mobil 1™ 15W-50 synthetic oil or
Castrol Syntec™ 5W-50 oil
Speeds Forward: 0-10 MPH (0-16.09 km/h)
@ 3400 rpm Reverse: 0-5 MPH (0-8.05 km/h)
Continuous Torque 222 ft. lbs. (301 Nm)
Output
Maximum Weight 750 lbs. (340 Kg)
on Axle
DIMENSIONS:
Overall Length 81” (208 cm)
Overall Width 72” (183 cm)
Height 70” (178 cm) with Roll Bar Up
59” (150 cm) with Roll Bar Down
Weight (apx..)
With 61” Mower Deck 1170 lbs. (531 kg)
BELTS AND BLADES:
Pump Drive Belt 5100555
Deck Drive Belt 5021724
Mower Blade 5020842
