VERTICAL POSITION COMMANDS
Set line spacing to 1/8 inch
27 48
IB 30
Sets the distance the paper advances in subsequent line feeds to 1/8 inch.
Set line spacing to 7/60 or 7/72 inch
27 49
IB 31
Setsthe distance thepaper advances in subsequentlinefeeds to 7/60 inch (standard
mode) or 7/72 inch (IBM mode).
Set line spacing to 1/6 inch
27 50 IB 32
Sets the distance the paper advances in subsequent line feeds to 1/6 inch.
Set line spacing to n/360 inch
[ [
I
I
Std.
<ESC> “+”
n 27 43 n IB 2B n
<FS> “3” n
28 51 n
IC 33 n
Sets the distance the paper advances in subsequent line feeds to n/360 inch, where
n is between Oand 255. .
Set base unit for line spacing
IBM
<ESC> “[” ‘A” <4>
<0> 27 91 92 4 0 IB 5B 5C 04 00
<O> <O> <O> n
O
00 00 00 n
Setsthe base unit for the line spacing commands, <ESC> “3” and <ESC> “J”. If
the value of n is 180,the base unit is set to 1/180”.If the value of n is 216, the base
unit is set to 1/216”. If otherwise specified, this command is ignored. This
command becomes effective only after <ESC> “3” or cESC> “J” is received, The
default base unit is set to 1/216”.
Chapter6 PRINTER CONTROL COMMANDS 49
