2-6 Sun StorEdge A3500 Hardware Configuration Guide • September 1998
2.1.2.2 Module ID Switch
Ensure that the module IDs for the StorEdge D1000 disk arrays are set according to
TABLE 2-1.
2.1.2.3 SCSI Jumper Cables and Terminators
All disk arrays in this configuration should have SCSI jumper cables between the
middle SCSI connectors (IN/OUT-1 and IN/OUT-2) and a differential SCSI
terminator in the far right SCSI connector (IN/OUT-2). This configuration is shown
in
FIGURE 2-15.
TABLE 2-1 1x5 Module ID Switch Settings
Disk array number Module ID setting
5 (Top) 5
44
33
22
1 (Bottom) 1
