Operations
Common
[Play icon]
The slideshow icon can be displayed.
Standard
The projector handles the slideshow icon as follows depending on the “On/Off” setting
of Icon on the projector’s menu.
Icon On: The projector displays the icon upon the start of playing a slide show and
turns it off after a few seconds.
Icon Off: The projector does not display the icon.
Continuous
The projector keeps the icon displayed during the slide show.
[Thumbnail display]
Select the form of a thumbnail list.
All: Displays a thumbnail preview of JPEG files, and if any JPEG files exist in the folder
displays the leading thumbnail image.
File: Displays only a thumbnail image of JPEG files. The thumbnail image of the JPEG
files in the folder is not displayed.
Off: Displays an icon without displaying thumbnail preview.
Note
Thumbnail image of MPEG files can not be displayed.
[Unplug device]
Run when unplugging a USB memory, a USB memory card reader/writer or a digital
camera and the like.
•
•
•
•
•
•
Checking the projector status
Status display
To check the current status of the projector, select Status display in step 2 in “Projector
settings”
p.50
. The following items of information will then be displayed.
Application
The name of the application currently running on the projector is
displayed.
(Examples: Slideshow, Network Utility)
Details When inputting from USB memory
“Free space/Status” are displayed.
When inputting from network
For wireless LAN, “MAC address/Mode/Channel/SSID/
Encryption/IP address/Subnet mask/Gateway” are displayed.
For wired LAN, “Connection status/MAC address/IP address/
Subnet mask/Gateway” are displayed.
PJLink class is displayed.
Version The firmware version number of the network feature and the USB
memory feature is displayed.
Using the Network Projector
Setting up the projector
Turn the projector power on.
Switch the input to Network.
Make sure to set the projector’s input to Network. If the other inputs are selected, the
projector will not be recognized by the computer.
A password prompt will be displayed.
A password prompt will be displayed only when [Password] is set to [On] in the
Application category of the Network Projector settings.
By referring to “Using the menus 2”, make the wireless LAN or wired
LAN settings.
Setting up the computer
Make the wireless LAN or wired LAN settings. Please see the helpMake the wireless LAN or wired LAN settings. Please see the help
function of your computer for details.
Open the [Connect to a Network Projector] wizard by clicking on the
[Start] button, by clicking [All Programs], then clicking [Accessories],
finally clicking [Connect to a Network Projector].
Select the desired projector from the list or enter the projector address.Select the desired projector from the list or enter the projector address.
When the password prompt is displayed in step
, enter the password.
N
N
N
Using the menus 2 (Continued)
