How can I get additional DC power cables?
Contact Digital Music to obtain additional cables.
What if I need a special cable?
Our Digital Music Custom Shop can provide any cable you
need.
What is a toroidal transformer and why does my Pedal Power
have one?
Power transformers create an magnetic field that can cause
hum and noise in your effects. A toroidal transformer has a
specially designed core that greatly reduces this electric field.
The Pedal Power uses this type of transformer so that your
pedal board is quiet.
Specifications
Input: IEC connector
120V 60Hz (North America)
100V 60Hz (Japan)
230V 50/60Hz (Europe/Australia)
Outputs: 5.5x2.1mm barrel connectors center negative
Eight 9VDC 100mA regulated
Four selectable to 12.3V (Boss ACA)
Two selectable to 200mA (Line6)
Two adjustable sag 4 to 9V
Short circuit protected.
Physical: 6” wide x 3.4” deep x 1.75” tall (152x86x45mm)
Weight 2 lbs. (0.9 kg).
Special: Toroidal power transformer.
Auxiliary AC outlet, 200 watts max.
