ACCLAIM LECTERN
- TABLETOP
AllModels
4
ACCLAIM LECTERN - CONTROL PANEL
ModelShown:ACL-7500U1
BASIC SYSTEM OPERATION
NOTE: Fully Charge Battery Before First DC Use!
1. SetallInputLevelControlstominimum&TonesControlstoat
(the
middlesetting)
beforeturningyoursystemon
2. PluglecterngooseneckmicrophoneintotheLecternMicJacklocatedon
thetabletop
3. PlugreadinglightintotheReadingLampJackoncontrolpanel
4. SwitchPOWERtoON,theBATTERYLEDwilllight
5. SlowlyincreasetheLevelControlfortheinputjacksused
tothedesiredvolume
6. AdjustBASS&TREBLEcontrolstodesiredsoundquality
IMPORTANT: Make all connections w/ shielded
cables to avoid hum, buzzing or interference.
LECTERN
MICROPHONE
JACK
BACK/CONTROL PANEL
FRONT/SPEAKER
LECTERN TOP
UHF WIRELESS RECEIVER
Availableonselectedmodelsonly
(pleaseseepage6forinstructions)
TONE CONTROLS
Bass&Treble
WIRED MICROPHONE
LEVEL CONTROL
LECTERN MIC LEVEL
CONTROL
POWER ON
INDICATOR LIGHT
READINGLAMPJACK
Removecaptouse
LINE IN LEVEL
CONTROL
AUXILIARY MICROPHONE
INPUTJACK–XLR
Balanced-lowimpedancemi-
crophones,powerscondenser
mics
SPEAKEROUT
OUTPUTJACK–1/4”PHONE
Balanced-drivesanunpowered
2ohmspeakerinadditiontothe
built-inspeakers
CHARGE INDICATOR LIGHT
(pleaseseepage3forinstructions)
BATTERY LEVEL INDICATOR LIGHT
ACCLAIM LECTERN -
CONNECTION PANEL
ModelShown:ACL-7500U1
LINE IN
INPUTJACK–1/4”PHONE
Jackmaybecombinedw/micinputsforacompositeoutput
Forplaybackoftape/CDplayerorotheraudiosource
LINE OUT
OUTPUTJACK–1/4”PHONE
Balanced-providescombined
outputofallactivesysteminputs
Recordpresentation/connecttoanother
poweredsoundsystem
INTERNALSPEAKERSWITCH
Turninternallecternspeakerout-
puton/off
BALANCED MICROPHONE
OUTPUTJACK–XLR
UsetoconnectAcclaimtoa
housesystem
Wasteelectricalandelectronicproductsmustnotbedisposedofwithhousehold
waste.Pleaserecyclewherefacilitiesexist.CheckwithyourLocalAuthorityor
Retailerforrecyclingadvice.
