100 Chapter 3
Removing the LCD Bezel
1. See “Removing the Battery Pack” on page 64.
2. See “Removing the Lower Cover” on page 65.
3. See “Removing the WLAN Board Modules” on page 67.
4. See “Removing the Keyboard” on page 71.
5. See “Removing the Middle Cover” on page 72.
6. See “Removing the LCD Module” on page 74.
7. Remove the four screw covers and the two rubber cover.
8. Remove the six screws (H) on the LCD module as shown.
Step Size (Quantity) Color Torque
1~6 M2 x L4 (6) Black 1.6 kgf-cm
