Chapter 1 25
VGA Subsystem
Item Specification
Chipset NVidia Graphic
Package nVIDIA MCP77
Features
• Dual Head Display Controller
• Full NVIDIA® nView™ multi-display technology
capability, with two independent display controllers
supporting a combination of any two of the following CRT,
TV,LVDS and HDMI/DVI/DP interfaces
• Each controller can drive same or different display
contents to different resolutions and refresh rates
• Video mirroring support
• Display Cache support CRT Display DAC
• 300 MHz RAMDAC for analog displays with resolutions
up to and including 1920 ×1440 at 60 Hz depending on
dual head and video configurations.
• Single channel TMDS interface for 25MHz to 165MHz
pixel data rate
• Support version 1.1 of the Display Port interface standard
for flat panel display, Projectors, PCs and CE devices.
• High-quality video scaling and filtering.
• Up to WUXGA resolution support on HDMI, and up to
2560 X 1600 resolution supporting Display Port mode.
• SPWG compliant
• Support for LCD panel EDID
• Power based on MCP67M:
• +NB_CORE for MCP77M CORE Power(+1.0V)
• +1.1V_NB for MCP77 Hyper Transport Power
• +1.1V for Hyper Transport, PCI-E, Sleep mode Core
power, SATA Interface, TV DAC supply
• +1.8V for LVDS digital supply
• +3.3V for PLL, CRTDAC, RGB DAC supply, USB
Interface, CPU Interface, LAN MAC, Display
Discrete Graphic (MXM)
• MSI MS-V115A3-9MGS256 (256MB)/ Yuan YSTP621GP
1(256MB)
• NVIDIA NB9M-GS (G3-64 package)
• Featuring:
• 16 Lane PCI Express support
• LVDS Interface support
• VGA support
• Video out support
• Upgradeable graphics
• Power: 19V, 5V, 3.3V, 2.5V, 1.8V
Power 19V, 5V, 3.3V, 2.5V, 1.8V
