Chapter 2. Installation
2-2 TSU User Manual 61200060L1-1
WIRING
Network
On the rear panel the TSU has an eight-position modular jack
labeled
NETWORK
. This connector is used for connecting to
the network. See Table 2-1 for the pinout for the Network
connector.
Connector Type - (USOC) RJ48C
pn - AMP# 555164-2
Power to the TSU must be from a 115 VAC, 60Hz that is grounded.
Table 2-1. Network Pin Connection
Network Pin Connection
PIN NAME DESCRIPTION
1 R1 RXDATA-RING Receive data from the Network
2 T1 RXDATA-TIP
3 UNUSED
4 R TXDATA-RING Send data towards the Network
5TTXDATA-TIP
6, 7, 8 UNUSED
