OSPF Application Example Configuring OSPF
page 1-32 OmniSwitch 6600 Family Advanced Routing Configuration Guide March 2005
OSPF Application Example
This section will demonstrate how to set up a simple OSPF network. It uses three routers, each with an
area. Each router uses three VLANs. A backbone connects all the routers. This section will demonstrate
how to set it up by explaining the necessary commands for each router.
The following diagram is a simple OSPF network. It will be created by the steps listed on the following
pages.
Three Area OSPF Network
Backbone Area
(Area 0.0.0.0)
Area 0.0.0.1
Router 1
Router ID 1.1.1.1
Area 0.0.0.2
Router 2
Router ID 20.0.0.1
Area 0.0.0.3
Router 3
Router ID 3.3.3.3
VLAN 10
Interface 10.0.0.1
VLAN 20
Interface 20.0.0.1
VLAN 12
Interface 12.x.x.x
VLAN 30
Interface 30.0.0.1
VLAN 23
Interface 23.x.x.x
VLAN 31
Interface 31.x.x.x
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
OmniSwitch 6648
