Modifying Advanced Properties
74
Wake on Pattern Match
The Wake on Pattern Match property specifies a condition when the
adapter wakes up from a low-power mode. The adapter wakes up when a
packet matches the wake patterns specified in the operating system, if the
Wake on Pattern Match and PCI PME properties are enabled.
Note
Even when you set the Wake on Pattern Match property to Enable,
the adapter stays in a low-power mode if the PCI PME property is
disabled. The Wake on Pattern Match property only specifies the
condition. To activate the WOL function to wake up the adapter, you
must enable the PCI PME property. See “PCI PME” on page 65.
To enable or disable the Wake on Pattern Match property, do the
following:
1. Access the Advanced Properties.
See “Accessing Advanced Properties” on page 60.
2. Select Wake on Pattern Match in the Property box.
The Wake on Pattern Match page is displayed as shown in Figure 41.
Figure 41. Wake on Pattern Match Page
