Product offerings and specifications are subject to change without notice. Actual products may vary
from photos. Not all products include all features. Availability varies by region; contact your sales rep.
LCD, PVM, Plasma & CRT Monitors
• 280+ TVL (AD950B); 750 TVL Y/C, 450
TVL composite (AD9517B)
• Comb filter for enhanced picture quality
• NTSC/PAL auto detect
• Universal power supply
• Two looping audio and video input pairs
(AD950B); (2 composite, 1 Y/C) for
AD9517B
• Auto termination
• Convenient front panel controls
AD950B dimensions:
220 x 222 x 305 mm
(8.66 x 8.74 x 12 in)
Weight: 6.8 kg (14.99 lbs)
•
AD9517B dimensions:
334 x 395 x 418.1 mm
(13.15 x 15.55 x 16.46 in)
Weight: 19.6 kg (43.21 lbs)
•
CRT Monitors & Mounts
51
—
52
9", 12" & 17" Black & White Monitor (High Resolution):
• 800+ TVL
• Video loop-through
• 2 looping BNC connectors
• EIA/CCIR selectable
• Auto termination
• Convenient front panel controls
•
Heavy duty metal cabinet and universal
latching power supply
• Dual rack mountable (9
”
only)
• AD9
10A dimensions:
234 x 220 x 248 mm (9.21 x 8.60 x 9.76 in)
Weight: 4.3 kg (9.46 lbs)
• AD9
12A dimensions:
305 x 302 x 287 mm (10.7 x 10.6 x 10.05 in)
Weight: 7.3 kg (16.1 lbs)
• AD9
17A dimensions:
385 x 415 x 390 mm (15.2 x 16.34 x 15.35 in)
Weight: 14 kg (30.9 lbs)
AD910A
AD912A
AD917A
AD910ARK (Rack mount)
AD917ARK (Rack mount)
AD950B
ADMM9CR (Rack mount)
AD9517B
AD9517RK (Rack mount)
RHM417WL (Wall mount)
RH213E3 (3 ft. Monitor extension)
RHEXT4 (4 ft. Ceiling extension)
RHEXT2 (2 ft. Ceiling extension)
9” & 17” Color Monitor (High Resolution):
ADMCRT15
AD9414RK (Rack mount)
RHM417WL (Wall mount)
RHM314ST
(Structural ceiling
mount
)
RHM314Su
(Suspended ceiling
mount
)
RHW314 (Wall mount)
RH213E3 (3 ft. Monitor extension)
RHEXT4 (4 ft. Ceiling extension)
RHEXT2 (2 ft. Ceiling extension)
15" Color Monitor (Standard Resolution):
• 280 TVL (10
"
)
• Two looping audio and video input pairs
• NTSC/PAL auto detect
• Auto termination
• Convenient front panel controls
• Universal power supply
•
Perfect for use with color quads
and multiplexers
• Heavy duty metal cabinet
•
Dimensions: 342 x 365 x 391 mm
(13.45 x 14.4 15.4 in)
• Weight: 15 kg (33 lbs)
