Introduction
1
10" Modero Widescreen Touch Panels
Introduction
The NXD-1000Vi Modero Widescreen Color Video Touch Panels with duplex intercom (FIG. 1) are the
industry’s first widescreen mini-touch panels and are available only through AMX.
These Color Video (CV) panels display NTSC/PAL/SECAM video formats within variable sized
windows. They include a built-in microphone, speaker, audio/headphone connector, and two NetLinx
programmable pushbuttons (available on NXD models only when mounted with included Button Trim
Ring).
Each panel is sold only as part of a kit which includes both a panel and an NXA-AVB/ETHERNET
Audio/Video Breakout Box (FG2254-10). This box facilitates the installation and distribution of video
(either Composite or S-Video), data (via Ethernet), and audio to Modero touch panels located up to 200
feet (60.96 m) from the breakout box. NXD-1000Vi panels are ideally suited for displaying full motion
video and audio with overlay graphics for applications with demanding visual requirements.
Key features include:
NXD-1000Vi panels are based on the latest display technology and support AMX's 4th
generation (G4) graphics which provide higher brightness, richer colors, and deeper contrast.
The new G4 graphics technology is supported by the latest AMX TPDesign4 Touch Panel
Design program.
NXD-1000Vi panels display eye-catching images and full-motion video on a large 16:9 image
format, while providing a wide 95-degree top-to-bottom viewing angle.
NXD-1000Vi panels feature a front panel light sensor, motion sensor, IR receiver and a Sleep/
Setup Access combo button.
FIG. 1 Sample 10" Video Touch Panel
NXD-1000Vi 10" Widescreen Video Touch Panel Kits
NXD-1000Vi
(FG2259-04)
10" Widescreen Color Video Wall Mount Touch Panel Kit (with buttons)
(includes both an NXD panel and an NXA-AVB/ETHERNET A/V Breakout Box).
The NXD-1000Vi panel (FG2259-04) is shipped, by default with a Trim Ring
containing buttons, but the end user can later install the included Trim Ring without
button openings.
