Introduction
3
10" Modero Widescreen Touch Panels
NXD-1000Vi Specifications
The following table outlines the specifications for the 10" Widescreen Modero panels.
Specifications for 10" Widescreen Video Touch Panels
Dimensions (HWD): • NXA-RK10(optional): metal rack-mount with black matte finish:
(5 RU - rack units high)
8.72" x 19.0" x 0.50" (22.15 cm x 48.26 cm x 1.27 cm)
• NXD-1000Vi (with faceplate): 7.96" x 11.16" x 3.32"
(20.22 cm x 28.34 cm x 8.43 cm)
• CB-TP10 Conduit/Wallbox (optional): 9.23" x 10.90" x 3.40"
(23.44 cm x 27.69 cm x 8.64 cm)
Power Requirements
(stand-alone NXD-1000Vi):
• Constant current draw: 1.1 A @ 12 VDC
• Startup current draw: 1.6 A @ 12 VDC
Memory (factory default): • 64 MB SDRAM
• 128 MB Compact Flash (upgradeable to 1 GB - factory programmed)
Weight (stand-alone): 2.65 lbs (1.20 kg)
Certifications: • FCC Part 15 Class B and CE
• IEC60950
Panel LCD Parameters: • Aspect ratio: 16 x 9
• Brightness (luminance): 350 cd/m
2
• Channel transparency: 8-bit Alpha blending
• Contrast ratio: 250:1
• Display colors: 256 thousand colors (18-bit color depth)
• Dot/pixel pitch: 0.28 mm
• Panel type: TFT Color Active-Matrix
• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Video format: NTSC, PAL, and SECAM
• Viewing angle (95° total viewing angle):
Vertical: + 45° (up from center) and - 65° (down from center)
Active Viewing Area: • 8.74” x 5.24” (22.20cm x 13.32cm)
IR Reception Angle: • Horizontal: +
50° (left and right from center)
•Vertical: +
30° (up and down from center)
Supported Audio Sample
Rates:
• 48000Hz, 44100Hz, 32000Hz, 24000Hz, 22050Hz, 16000Hz, 12000Hz,
11025Hz, and 8000Hz.
