3. Power-ON computer and monitor
Power-ON the computer, then Power-ON the monitor.
4. Windows users:
Setting the Timing Mode (Resolution and Refresh Rate)
Example: 1440 x 900 @ 60 Hz
Resolution
Right-click on the Windows desktop > Properties > Settings >
“Desktop Area”. Set the resolution.
Refresh Rate
(vertical frequency) See your graphic card’s user guide for
instructions.
Connection Diagram:
5
1.
Connect Power cord
Connect the power cord to a properly grounded AC outlet, then to the monitor.
2. Connect Analog video cable (D-Sub cable)
Make sure both monitor and computer are powered OFF. Connect the video
cable ( D-Sub cable) to the computer, then to the monitor.
Connecting the Monitor
English
