Xserve RAID Locking Switch -
4
Closing Xserve RAID
1. Place the cover on top of the enclosure so that it is approximately 1/4 inch back from
the front bezel.
(Figure 4)
Note:
The left and right sides of the cover should fit inside the enclosure.
2. Slide the cover forward so that the two tabs on the front of the cover engage with the
slots in the bezel.
Note:
Make sure that the screw holes in the cover and sides of the enclosure align.
Figure 4
3. Replace the 16 mounting screws on the left and right sides of the cover.
