Basics Signals on the Video Connector - 12
Signals on the Video Connector
Pin Signal Name Description
1 RED Red video signal
2 GREEN Green video signal
3 BLUE Blue video signal
4 MONID(0) Monitor ID signal 0
5 GND DDC return
6, 7, 8 AGND_VID Analog video ground
9 +5V_IO 5 V Power for I/O device
10 GND HSYNC & VSYNC Ground
11 VGA_ID VGA ID signal
12 MONID(2) Monitor ID signal 2
13 HSYNC Horizontal
synchronization signal
14 VSYNC Vertical synchronization
signal
15 MONID(1) Monitor ID signal 1
