HEADPHONES
HEADPHONES
AUDIO R AUDIO L VIDEO
-11-
OPTIONAL ACCESSORIES
Wireless Headphones
The LCM0802TV includes a RF transmitter (P/N
WUX) for use with optional Flexvision wireless
headphones. Tuning the headphone switch on, and
wearing them activates the internal micro switch,
(which includes a tuning knob to tune into the preset
frequency on the RF transmitter), which will activate
the internal RF receiver and the volume can be
adjusted separately with the controls on the headset.
See the documentation accompanying your Flexvision
wireless headphones.
Auxiliary A/V Stereo Inputs Jack
The LCM0802TV may be equipped with an auxiliary
A/V stereo input connector (optional).
These inputs are provided to facilitate the temporary
connection of optional audio/video equipment, such as
a camcorder or video game system. To play a source
with these inputs, an RCA patch cord is required to
connect the audio/video signals to their respective
jacks. Mono audio sources will require the use of an
RCA Y-cable (P/N 0892165) to connect to both right
and left inputs, if patch cords are installed into the
AUX inputs, the AUX INPUT 2 will be temporarily
bypassed. Once the connections have been made,
turn the LCM0802TV on and press the source button
on the LCM0802TV or the TV/Video button on the
remote control until “Video 2” is displayed on the
screen. The unit will now play the audio and video
signals from the accessory connected. The remote
control will not operate the accessory components.
LCM0802TV Jack Panel
