Asus A7N8X-VM 400 Computer Hardware User Manual



ix
A7N8X-VM 400 specifications summary
CPU
Chipset
Front Side Bus (FSB)
Memory
Expansion slots
IDE
Graphics
Audio
LAN
IEEE 1394 (optional)
Hardware Monitoring
Special Features
Back Panel I/O Ports
Internal I/O
Connectors
(continued on the next page)
Socket A Type 462 for AMD Athlon™/Athlon™ XP CPUs
400/333/266 MHz FSB Support
NVIDIA
®
nForce2 IGP North bridge controller
NVIDIA
®
nForce2 MCP2 (MCP2-T optional) South bridge
400/333/266 Mhz
2 x 184-pin DDR DIMM Sockets
Maximum 2 GB unbuffered PC2700/2100 non-ECC DDR
RAM memory.
3 x PCI
1 x AGP 8X (1.5V only)
2 x UltraATA 133/100/66/33
Integrated nForce 2 with TV-out
Supports UMA Mode
Realtek ALC650 6CH Audio CODEC linked w/ South Bridge
Realtek 8201BL PHY 10/100 Mbps
Agere FW802C PHY supports up to 400Mbps data transfers
Super I/O integrated monitoring of CPU/chassis fan rotation
and MB/CPU temperature
S/PDIF in/out support
1 x Parallel
1 x Serial
1 x PS/2 Keyboard
1 x PS/2 Mouse
1 x RJ45 port
1 x Audio I/O
1 x VGA port
2 x USB 2.0/1.1
2 x USB connectors support additional 4 USB 2.0/1.1 ports
CPU/chassis FAN connectors
Chassis intrusion connector
20-pin ATX power connector
PANEL connector
CD / AUX connectors
S/PDIF in/out connector
GAME/MIDI connector
TV out connector
Serial connector
Front panel audio connector
