Striker II Extreme / Striker II NSEStriker II NSE
specications summary
CPU LGA775 socket for Intel
®
Core™2 Quad /
Core™2 Extreme / Core™2 Duo / Pentium
®
Extreme /
Pentium
®
D / Pentium
®
4 processors
Supports Intel
®
next-generation 45nm multi-core CPUs
Compatible with Intel
®
06/05B/05A processors06/05B/05A processors05B/05A processors
* Refer to www.asus.com for Intel CPU support list
Chipset Striker II Extreme: NVIDIA
®
nForce
®
790i Ultra SLI™
Striker II NSE: NVIDIA
®
nForce
®
790i SLI™
System Bus 
Memory Dual-channel memory architecture supports NVIDIA
®
SLI™-ready memory technologySLI™-ready memory technology
- 4 x 240-pin DIMM sockets support unbuffered
non-ECC DDR3 2000 (O.C.)/1800(O.C.)/non-ECC DDR3 2000 (O.C.)/1800(O.C.)/(O.C.)//
    
(Striker II Extreme)Striker II Extreme))
- 4 x 240-pin DIMM sockets support unbuffered

memory modules (Striker II NSE)
- Supports up to 8 GB system memory
*Refer to www.asus.com or this user manual for the
    
Expansion Slots 2 x PCIe 2.0 x16 slots (support NVIDIANVIDIA
®
SLI™
   

2 x PCIe x1 slots (PCIEX1_1 (black) is compatible with
the audio slot.)the audio slot.)
2 x PCI 2.2 slots
Scalable Link Interface
(SLI™)
Supports NVIDIA
®
3-way SLI graphics cards (triple at x16
mode)mode)
Storage Southbridge supports:
- 1 x UltraDMA 133/100/66/33
- 6 x SATA 3.0 Gb/s6 x SATA 3.0 Gb/s
- NVIDIANVIDIA
®
MediaShield™ RAID supports RAID 0, 1,
       
drivesdrives
JMicron
®
JMB363 SATA controller
- 2 x External SATA 3.0 Gb/s port (SATA On-the-Go)
LAN Dual Gigabit LAN, both featuring AI NET 2
Supports Teaming Technology
High Denition Audio SupremeFX II Audio Card
 
- Noise Filter
Coaxial / Optical S/PDIF Out ports at back I/O
(continued on the next page)
