ix
(continued on the next page)
F2A85-M specications summary
APU AMD
®
A- series accelerated processors with AMD
®
Radeon™ HD 7000
series graphics, up to 4 CPU cores, FM2 package
Supports AMD
®
Turbo Core Technology 3.0
Supports DirectX
®
11
• The AMD
®
Turbo Core Technology 3.0 support depends on the APU types.
• Refer to
www.asus.com for AMD APU support list.
Chipset AMD
®
A85X FCH(Hudson D4)
Memory 4 x 240-pin DIMM slots support maximum 64GB unbuffered non-ECC
DDR3 2400(O.C.)/2250(O.C.)/2200(O.C.)/2133(O.C.)/2000(O.C.)/1866/
1600/1333/1066MHz memory modules
Dual-channel memory architecture
* The maximum 64GB memory capacity can be supported with 16GB or above
DIMMs. ASUS will update the memory QVL once the DIMMs are available in the
market.
** Refer to www.asus.com for the latest Memory QVL (Qualied Vendors List).
*** When you install a total memory of 4GB capacity or more, Windows
®
32-bit
operation system may only recognize less than 3GB. We recommend
a maximum of 3GB system memory if you are using a Windows
®
32-bit
operating system.
Graphics Integrated AMD Radeon™ HD 7000 Series Graphics in Trinity APU
Multi-VGA output support: HDMI/DVI/D-Sub port
- Supports HDMI with max. resolution 1920x1080@60Hz
- Supports Dual-link DVI with max. resolution 2560x1600@60Hz
- Supports D-Sub with max. resolution 1920x1600@60Hz
- Supports Microsoft
®
DirectX 11
- Maximum shared memory of 2G
- Supports AMD
®
Dual Graphics technology
* Refer to www.amd.com for the discrete GPUs which support Dual
Graphics technology
Expansion slots 2 x PCI Express 2.0 x16 slots (blue @ x16 mode, black @ x4 mode)
1 x PCI Express 2.0 x1 slot
1 x PCI slot
Multi-GPU support
Supports AMD CrossFireX™ Technology (x16 & x4)
Storage / RAID
AMD
®
A85X FCH:
- 7x Serial ATA 6Gb/s connectors(gray) with RAID 0, RAID 1,RAID
5,RAID 10 and JBOD support
- 1x eSerial ATA 6Gb/s at the back I/O
LAN
Realtek
®
8111F Gigabit LAN controller
Audio Realtek
®
ALC887 8-Channel High Denition Audio CODEC
- Support 192khz/24bit BD lossless sound
- BD Audio Layer Content Protection
- Supports Jack-Detection, Multi-streaming, Front Panel Jack-Retasking
- Optical S/PDIF out port at back I/O
USB
AMD
®
A85X FCH :
- 4 x USB 3.0/2.0 ports (2 ports at back panel, [blue], 2 ports at mid-
board)
- 10 x USB2.0/1.1 ports (4 ports at back panel, 6 ports at mid-board)
