ASUS M2N32 WS Professional 4-21
DDR2 Voltage Control [Auto]
Allows you to set the operating DDR2 voltage.
Conguration options: [Auto] [1.800V] [1.825V] [1.850V] ~ [2.500V]
CPU Multiplier [Auto]
Allows you to set the operating CPU multiplier. The conguration options may vary
depending on the type of CPU installed. Conguration options: [Auto] [5x] [6x] ~
[13x]
CPU Voltage [Auto]
Allows you to set the operating CPU voltage.
Conguration options: [Auto] [1.400v] [1.375v] ...[0.800v]
Advanced Voltage Control
F1:Help ↑↓ : Select Item -/+: Change Value F5: Setup Defaults
ESC: Exit →←: Select Menu Enter: Select Sub-menu F10: Save and Exit
Select Menu
Item Specic Help
Set NB Core/PCI-E Voltage.
Advanced Voltage Control
P_+1.2V Voltage [Auto]
P_VTTDDR_SW Voltage [0.5*+1.8V]
P_+1.5V Voltage [Auto]
Vcore Offset Voltage [+ 50mV]
P_+1.2V HT Voltage [+1.250V]
P_+1.3V HT MCP Voltage [Auto]
P_+1.5VSB Voltage [+1.500V]
Phoenix-Award BIOS CMOS Setup Utility
Advanced
P_+1.2V Voltage [Auto]
Allows you to set the P_+1.2V voltage.
Configuration options: [Auto] [+1.20V] [+1.25V] [+1.30V] [+1.35V] [+1.40V]
P_VTTDDR_SW Voltage [0.5*+1.8V]
Allows you to set the P_VTTDDR_SW voltage.
Configuration options: [Auto] [0.5*+1.8V] [0.6*+1.8V]
P_+1.5V Voltage [Auto]
Allows you to set the P_+1.5V voltage.
Configuration options: [Auto] [+1.500V] [+1.525V] [+1.550V] [+1.575V]... [+1.700V]
