xii
High Denition audio ADI
®
AD1988B 8-channel High Denition audio CODEC
- Supports Jack-Detection, Enumeration, Multi-
Streaming, and Jack-Retasking
- Coaxial/Optical S/PDIF Out ports at back I/O
IEEE 1394 2 x IEEE 1394a connectors (1 at mid-board; 1 on the rear
panel)
USB 10 x USB 2.0 ports (4 at mid-board; 6 on the rear panel)
ASUS AI Lifestyle
unique features
ASUS Quiet Thermal Solution:
- ASUS Fanless Design: Cool Mempipe solution
(WiFi-AP Edition only)
- ASUS AI Gear 2
- ASUS 8+2 Phase Power Design
- ASUS AI Nap
- ASUS Fanless Design: Heat-pipe solution & Stack
Cool 2
- ASUS Q-Fan 2
ASUS Crystal Sound
- ASUS Noise Filter
- ASUS AI Audio 2
ASUS EZ DIY
- ASUS Q-Shield
- ASUS Q-Connector
- ASUS O.C. Prole
- ASUS CrashFree BIOS 3
- ASUS EZ Flash 2
Other features ASUS MyLogo 2™
Multi-language BIOS
ASUS exclusive
overclocking features
Intelligent overclocking tools:
- AI NOS
™
(Non-delay Overclocking System)
- AI Overclocking (intelligent CPU frequency tuner)
- ASUS AI Booster utility
Precision Tweaker 2:
- vCore: Adjustable CPU voltage at 0.0125V
increment
- vDIMM: 35-step DRAM voltage control
- vChipset: 16-step Chipset voltage control
SFS (Stepless Frequency Selection):
- FSB tuning from 100 MHz up to 600 MHz at 1 MHz
increment
- Memory tuning from 533 MHz up to 1066 MHz
- PCI Express frequency tuning from 100 MHz to 150
MHz at 1 MHz increment
Overclocking protection:
- ASUS C.P.R. (CPU Parameter Recall)
(continued on the next page)
M3A32-MVP Deluxe Series
specications summary
