ASUS M5A97 EVO R2.0
3-33
Chapter 3
3.8.2 ASUS SPD Information
This item allows you to get DRAM SPD information.
3.8 Tools menu
The Tools menu items allow you to congure options for special functions. Select an item
then press <Enter> to display the submenu.
3.8.1 ASUS EZ Flash 2 Utility
Allows you to run ASUS EZ Flash 2. When you press <Enter>, a conrmation message
appears. Use the left/right arrow key to select between [Yes] or [No], then press <Enter> to
conrm your choice.
For more details, refer to section 3.10.2 ASUS EZ Flash 2 utility.
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
Be used to update BIOS
UEFI BIOS Utility - Advanced Mode
> ASUS EZ Flash 2 Utility
> ASUS SPD Information
> ASUS O.C. Prole
Main
Ai Tweaker
Advanced Monitor Boot Tool
Exit
DIMM Slot number
UEFI BIOS Utility - Advanced Mode
→←: Select Screen
↑↓: Select Item
Enter: Select
+/-: Change Opt.
F1: General Help
F2: Previous Values
F3: Shortcut
F5: Optimized Defaults
F10: Save ESC: Exit
F12: Print Screen
DIMM Slot # Slot 2
Manufacturer Corsair
Module Size 1024 MBytes
Maximum Bandwidth 1333 MHz
Part Number CM3X1024-1600C7DHN
Serial Number
Product Week/Year 22/2012
SPD Ext. XMP
XMP Rev. 1.0
JEDEC ID JEDEC XMP #1 XMP#2
Frequency (Mhz) 1333
Voltage (V) 1.500
CAS# Latency (tCL) 9
RAS# to CAS# (tRCD) 9
RAS# Precharge (tRP) 9
tRAS 24
tRC 33
tWR 10
tRRD 4
tRFC 60
tWTR 5
tRTP 5
tFAW 20
tCWL
Command Rate
Back Tool\ ASUS SPD Information >
