1-28 Chapter 1: Product introduction
8. Intel
®
H77 Serial ATA 3.0Gb/s connectors (7-pin SATA3G_1~4 [blue])
These connectors connect to Serial ATA 3.0 Gb/s hard disk drives and optical drives via
Serial ATA 3.0 Gb/s signal cables.
• These connectors are set to [IDE] by default. If you intend to create a Serial ATA RAID
set using these connectors, set the SATA Mode Selection item in the BIOS to [RAID].
See section 2.5.3 SATA Conguration for details.
• Before creating a RAID set, refer to the RAID Supplementary Guide included in the
folder named Manual in the support DVD.
• You must install Windows
®
XP Service Pack 3 or later version before using Serial ATA
hard disk drives. The Serial ATA RAID feature (RAID 0, 1, 5, and 10) is available only if
you are using Windows
®
XP SP3 or later version.
• When using hot-plug and NCQ, set the SATA Mode Selection item in the BIOS to
[AHCI]. See section 2.5.3 SATA Conguration for details.
S
AT
A3G_
2
G
N
D
R
SATA
_
R
XP
2
R
SATA
_
R
XN
2
G
N
D
R
SA
TA_T
X
N
2
R
SATA
_
TX
P
2
G
N
D
S
AT
A3G_
1
G
N
D
R
SATA_R
XP
1
R
SATA
_
R
XN
1
G
N
D
R
SATA_T
X
N
1
R
SATA_T
X
P
1
G
N
D
S
AT
A3G_
4
G
N
D
R
SATA
_
R
XP
4
R
SATA
_
R
XN
4
G
N
D
R
SA
TA_T
X
N
4
R
SATA
_
TX
P
4
G
N
D
S
AT
A3G_
3
G
N
D
R
SATA_R
XP
3
R
SATA_R
XN
3
G
N
D
R
SATA_T
X
N
3
R
SATA
_
TX
P
3
G
N
D
P8H77-M LE
P8H77-M LE Intel
®
SATA 3.0Gb/s connectors
9. USB 2.0 connectors (10-1 pin USB56, USB78, USB910)
These connectors are for USB 2.0 ports. Connect the USB module cable to any of
these connectors, then install the module to a slot opening at the back of the system
chassis. These USB connectors comply with USB 2.0 specication that supports up to
480 Mbps connection speed.
Never connect a 1394 cable to the USB connectors. Doing so will damage the motherboard!
The USB module cable is purchased separately.
P8H77-M LE
P8H77-M LE USB2.0 connector
PIN 1
USB+5V
USB_P8-
USB_P8+
GND
NC
USB+5V
USB_P7-
USB_P7+
GND
USB78
PIN 1
USB+5V
USB_P10-
USB_P10+
GND
NC
USB+5V
USB_P9-
USB_P9+
GND
USB910
PIN 1
USB+5V
USB_P6-
USB_P6+
GND
NC
USB+5V
USB_P5-
USB_P5+
GND
USB56
