(continued on the next page)
P8Z77-V LE specications summary
Storage Intel
®
Z77 Express Chipset:
- 2 x Serial ATA 6.0 Gb/s connectors (gray) with RAID 0, 1, 5, 10 support
- 4 x Serial ATA 3.0 Gb/s connectors (blue) with RAID 0, 1, 5, 10 support
- Supports Intel
®
Smart Response Technology, Intel
®
Rapid Start
Technology, Intel
®
Smart Connect Technology*
Marvell
®
PCIe SATA 6Gb/s controller**:
- 1 x eSATA port at the back I/O (6.0 Gb/s ready)
- 1 x Serial ATA 6.0 Gb/s connectors (navy blue)
* Supports on Intel
®
Core
TM
processor family with Windows
®
7 Operating Systems.
** These SATA ports are for data storage only. ATAPI devices are not supported.
LAN
Realtek
®
8111F Gigabit LAN controller
Audio Realtek
®
ALC892 8-channel High Denition Audio CODEC
- Support 192khz/24bit BD lossless sound
- BD Audio Layer Content Protection
- Supports Jack-Detection, Multi-streaming and Front Panel Jack-Retasking
- Optical S/PDIF out ports at back I/O
USB Intel
®
Z77 Express Chipset - supports ASUS USB 3.0 Boost UASP Mode*
- 2 x USB 3.0 / 2.0 ports at the mid-board for front panel support
- 2 x USB 3.0 / 2.0 ports at the back panel (blue)
Intel
®
Z77 Express Chipset
- 10 x USB 2.0 ports (8 ports at mid-board, 2 ports at back panel)
ASMedia USB 3.0 controllers - supports ASUS USB 3.0 Boost UASP Mode
- 2 x USB 3.0 ports at back panel (blue)
* The USB 3.0 ports only support Windows
®
7 or later versions. UASP standard
only supports Windows
®
8.
ASUS unique
features
ASUS Dual Intelligent Processors 3 - SMART DIGI+ Power Control:
SMART DIGI+
- Smart DIGI+ Key - quickly delivers higher VRM frequency, voltage and current
for superior CPU/iGPU/DRAM overclocking performance with one switch.
- Smart CPU Power Level (Intel
®
VRD 12.5 Future Power Design) - provides the
best digital power saving conditions.
CPU Power
- Industry leading digital 8-phase power design (6-phase for CPU, 2-phase for
iGPU)
- ASUS CPU power utility
DRAM Power
- Industry leading ditital 2-phase DRAM power design
- ASUS DRAM power utility
ASUS EPU
- EPU, EPU Switch
ASUS TPU
- Auto Tuning, TurboV, GPU Boost, TPU switch
