3-2 Chapter 3: General Instruction
OSD menu table:
Main Sub-menu 1 Sub-menu 2 Description
Splendid
Scenery Mode Reset (NO/YES)
Video preset mode for viewing scenery
Standard Mode Reset (NO/YES)
Video preset mode for generic windows use
Theater Mode Reset (NO/YES)
Video preset mode for watching movies
Game Mode Reset (NO/YES)
Video preset mode for playing games
Night View Mode Reset (NO/YES)
Video preset mode for displaying night views
Brightness 0~100
Adjusts brightness of the image
Contrast 0~100
Adjusts contrast of the image
ASCR* ON/OFF
Enables/disables the ASCR function
Sharpness* 0~100
Adjusts sharpness of the image
Satuation* 0~100
Adjusts saturation of the image
Position**
(For VGA only)
H-Position
Adjusts horizintal position of the image
V-Position
Adjusts vertical position of the image
Focus**
(For VGA only)
Phase
Reduces the horizontal-line noise of the image
Clock
Reduces the vertical-line noise of the image
Color
Color Temp Cool
The image appears bluer
Normal
Normal image color
Warm
The image appears redder
sRGB***
The image appears sRGB standard color for multimedia
designers
User Mode
Adjusts Red/Green/Blue levels of the image
Skin Tone* Reddish
Selects reddish skin stone
Natural
Selects natural skin stone
Yellowish
Selects yellowish skin stone
Sound
Preset Mode Standard Mode
Sound preset mode for generic windows use
Fighting Game Mode
Sound preset mode for playing ghting games
Strategic Game Mode
Sound preset mode for playing strategic games
Theater Mode
Sound preset mode for watching movies
Music Mode
Sound preset mode for listen to music
SRS TSXT ON/OFF
Enables/disables the SRS TSXT sound effect
TruBass**** 0~10
Adjusts the TruBass bass level while SRS TSXT is on
Balance -10~+10
Adjusts the balance between right and left channel sounds
Equalizer 100/300/1K/3K/10K Hz
Adjusts 5 bands (100Hz, 300Hz, 1KHz, 3KHz, 10KHz)
Melody ON/OFF
Enables/disables the melody function
Power Key*****
Selects 1 of 4 power on/off melodies
Function Key*****
Selects 1 of 6 function key tones
Input Select
VGA/DVI/Video/S-Video/YPbPr/Music
Selects a preferred input source
System Setup
Aspect Control
(AV only)
Full/4:3/Panorama/
Zoom
Adjusts the aspect ratio while in Video/S-Video/YPbPr mode
Aspect Control
(PC only)
Full/4:3/1:1
Adjusts the aspect ratio while in VGA/DVI mode
Light-in-Motion 0~4
Adjusts the luminance of the Light-in-Motion lighting effect
OSD Setup H-Position
Adjusts horizontal position of the OSD
V-Position
Adjusts vertical position of the OSD
OSD Timeout
Adjusts OSD timeout
Language
Selects a preferred language among 11 languages
Information
Shows the resolution,H/V frequency and input port of current input timing
All Reset NO/YES
Returns to default setting
*
: the function is disabled only when the "Standard Mode" of Spendid is selected.
**
: the function is enabled only when the VGA input is selected.
***
: the function is enabled only when the "Standard Mode" of Spendid is selected.
****
: the function is enabled only when the SRS TSXT function is activated.
*****
: the function is enabled only when the Melody function is activated.
