xiii
ASUS Exclusive
Features
Q-Design
- ASUS Q-Code
- ASUS Q-Shield
- ASUS Q-LED (CPU, DRAM, VGA, Boot Device LED)
- ASUS Q-Slot
- ASUS Q-DIMM
- ASUS Q-Connector
ASUS Special Features
5X Protection featuring all-round protection provides the best
quality, reliability, and durability
USB 3.0 Boost
USB Charger+
Ai Charger+
Disk Unlocker
AI Suite 3
MemOK!
EZ XMP
ASUS Quiet Thermal
Solution
Quiet Thermal Design
- ASUS Fan Xpert 3
- ASUS Fanless Design: Heat-pipe solution
ASUS Exclusive
Overclocking Features
Precision Tweaker 2
- vCore: Adjustable CPU Core voltage at 0.001 V increment
- iGPU: Adjustable CPU Graphics voltage at 0.001 V increment
- vCCIO: Adjustable Analog and Digital I/O voltage at 0.001 V
increment
- vCCIN: Adjustable CPU Input voltage at 0.01 V increment
- vCCSA: Adjustable CPU System Agent voltage at 0.001 V
increment
- vDRAM Bus: 144-step Memory voltage control
- vPCH: 88-step Chipset voltage control
SFS (Stepless Frequency Selection)
- BCLK/PCIE frequency tuning from 80 MHz to 300 MHz at 0.1
MHz increment.
Overclocking Protection
- ASUS C.P.R. (CPU Parameter Recall)
Rear Panel I/O Ports
1 x DisplayPort
1 x Mini DisplayPort
1 x HDMI port
1 x ASUS Wi-Fi GO! module (Wi-Fi 802.11 a/b/g/n/ac and Bluetooth
v 4.0)
1 x Optical S/PDIF Out port
2 x LAN (RJ45) ports (2 x Intel
®
LAN)
6 x USB 3.0/2.0 ports (blue, bottom port of USB3_34 supports USB
BIOS Flashback)
4 x USB 2.0/1.1 ports
8-channel Audio I/O ports
Z97-DELUXE specifications summary
(continued on the next page)
