AXIS Q7900 Installation Guide Page 11
ENGLISH
Replacing a fan
Follow these steps to replace a fan.
1. Loosen and remove the screws located on each side of the fan that needs to be replaced.
2. Gently pull out the fan far enough to disconnect it from the power connector.
3. Disconnect the fan and remove it completely.
4. Insert a new fan and reconnect it to the power connector.
5. Replace and retighten the screws.
Note:
If one fan needs to be replaced, it is best to replace all three fans as soon as possible for optimum
performance.
Power connector
Screws
