ToughRunners / ScanWear – Communication Protocol v1.2 - 40 -
Data Capture
for Workforce
in Motion
Standard 2 of 5 and MSI parameters:
OP25S Description Default
b0 Reserved (do not modify) 1
b1
(0,0) : 1 fixed allowed length (specified in LES1)
(1,0) : 2 fixed allowed lengths (specified in LES1 and LES2)
(0,1) : 3 fixed allowed lengths (specified in LES1, LES2 and
LES3)
(1,1) : any length allowed (>4)
1
b2 1
b3 Check digit not transmitted 0
b4 Check digit not calculated 1
b5
Code MSI Check Digit
(0,0): not calculated
(1,0): Modulo 11
(0,1): Double modulo 10
(1,1) : Modulo 10
1
b6 1
b7 Code MSI check digit not transmitted 0
LES1 / LES2 / LES3 Description Default
n
0: No length test
>0: Authorise n-character barcodes
0
Nota :
If one length allowed, specify it in LES1.
If two lengths allowed, fill LES1and LES2 with positive values.
If zero is specified and the (b1,b2) bits of OP25S are not (1,1) then the first standard 2/5
decoded barcode will fix the length.
CODABAR et PLESSEY parameters :
OPMON Description Default
b0 Reserved (do not modify) 1
b1 Reserved (do not modify) 1
b2
Start/Stop CODABAR
(0,0) : start/stop abcd/abcd
(1,0) : start/stop ABCD,ABCD
(0,1) : start/stop abcd,tn*e
(1,1) : standard
0
b3 0
b4 Reserved (do not modify) 0
b5 Reserved (do not modify) 1
b6 Reserved (do not modify) 1
b7 Code PLESSEY check digit not transmitted 1
UPC/EAN parameters :
OPEAN1 Description Default
b0 Validation UPCA 1
b1 Validation UPCE 1
b2 Validation EAN8 1
b3 Validation EAN13 1
b4 ADD-ON required and transmitted (**) 0
b5 ADD-ON disabled 1
b6 UPCA number system not transmitted 0
b7 UPCA check digit not transmitted 0
(**) when decoded, the add-on is transmitted.
