Black Box Console Server user guide 134
CISCO RJ45 console ports with software flow control
Black Box 833AS
Black Box Series router console port
Console Server CISC0
TX 5 ————————> 6 RX
RX 6 <———————— 3 TX
GND 4 <———————— 4 GND
Console Server 833AS
DB9
TX 5 ————————> 2 RX
RX 6 <———————— 3 TX
GND 4 ————————— 5 GND
Console Server Router
DB25
TX 5 ————————> 2 RX
RX 6 <———————— 3 TX
GND 4 ————————— 7 GND
