1.Specifications
Cable Required: Between transmitter and receiver: Cat5/Cat6
Compliance: CE; FCC Class A, IC Class A
Video Support: DVI Single Link
Resolution: 1600x1200 , 1080P (if graphics card supports reduced clock rate)
Transmission: Transparent to users
Bandwidth: 1.65 Gbps
Maximum Total end to end over CAT5/CAT6: 600 ft (183m).
Distance:
Connectors: AC1100A: (1) RJ45, (2) DVI F;
AC1101A: (1) RJ-45, (1) DVI F;
AC1102A: (2) RJ-45, (1) DVI F;
All: (1) power inlet
Temperature Operating: 32 to 104°F (0 to 40°C);
Tolerance: Storage: -4 to +140°F (-20 to +60°C)
Humidity
Tolerance: Up to 80% noncondensing
Enclosure: Steel
Power: From utility-power (mains) outlet to power inlet, through
detachable external power supply: Input: 100 to 250 VAC
@ 50 or 60 Hz (autosensing);
Output: +5 VDC;
Consumption: 5 watts maximum
Size: 1.2"H x 4.1"W x 5.5"D (3.1 x 10.4 x 14.0 cm)
Weight: 1.0 lb. (0.45 kg) (all units)
CHAPTER 1: Specifications MULTI DVI SYSTEM.
15
2. Introduction
2.1 Overview
The Multi DVI System extends DVI video signals over Cat5/6 cable. All models support
single link DVI video modes.
This manual covers Multi DVI System units for video (AC1100A, AC1101A, AC1102A).
Multi DVI System receivers are available with single or dual daisychainable
connections. The dual daisychainable receiver is used when the same signal is
distributed to multiple display devices across a single cable in a daisychain or loop-
through fashion. Setup and cabling are the same as the single-port receiver.
WARNING
This equipment is not intended for, nor does it support, distribution
through an Ethernet fiber network. Do not connect these devices to any sort
of networking or telecommunications equipment!
2.2 Package Contents
You should have received the following when ordering a Multi DVI System
receiver:
• The transmitter or receiver. unit
• External power supply (100–250 VAC, 50–60 Hz, autosensing) with cord.
• This manual.
2.3 Equipment You May Also Need
• Rackmount Brackets:
For or single-port/dual daisychainable receivers:
AC1011 for 3 units; AC1012 for 6 units;
• Stereo Audio cable.
• DVI Video cable.
• Serial cable.
2.4 Compatible Cabling
Cabling for the Multi DVI System must be Cat5/Cat6 cable pinned to the EIA T568B
specification (see Appendix A).
