OPERATION MANUAL
-6-
Settings on the Control Panel
You can change some of the FAX settings on the printer control panel.
HL-2060/HL-2400 Series/HL-3400N series
1. Press the SEL switch to make the printer off-line.
2. Press the MODE switch to enter the Mode Menu. Then, ‘INTERFACE MODE’ is
displayed.
3. Press the SET switch until ‘ADVANCED MODE’ is displayed.
4. Press the SET switch.
5. Press the SET switch until ‘FAX MODE’ is displayed.
6. Press the SET switch.
HL-2460
1. Press the ‘+’ to until ‘INTERFACE MODE’ is displayed on the printer front panel,
and then press the ‘SET’ button.
2. At the INTERFACE menu, press the ‘+’ or ‘-‘ keys until ‘RS-232C’ is displayed, then
press the ‘SET’ button.
3. Press the ‘+’ or ‘-‘ keys to scroll through the different options. Press the SET button to
select a setting and then change.
Menu Descriptions
RING DELAY
Number of rings before the printer answers when receiving fax data.
Select from 0 to 4. The factory default setting is 2.
REDUCTION
Set if the received fax data is reduced for printing or not.
AUTO: reduced automatically (factory default setting)
OFF: not reduced automatically
90%: reduced to 90%
FAX RAM
SIZE
Set the RAM size used for the fax function.
After turning the printer off and on the setting is active.
The factory setting is 1MB.
The maximum size that can be set is 15 MB, this depends on the
memory size installed into the printer.
RECEIVE
Select if the printer is to receive fax data or not.
When the printer only sends Fax data, select this to OFF.
ON: Receive fax data (factory default setting)
OFF: Does not receive fax data
INTERVAL
Set the interval to print a fax sent / received report. The factory
setting is OFF.
Select one of the following 7 types.
OFF: No printing
6H: every 6 hours, 12H: every 12 hours, 24H: every 24 hours
2D: every 2 days, 4D: every 4 days, 7D: every 7 days
