INTRODUCTION 1 - 3
Control Panel Overview
FAX-4100, FAX-4750e and FAX-5750e have the same control panel keys.
1Toner Empty Icon
The Toner icon flashes on and off when
toner is low, so you’ll know to order
another toner cartridge. You will be
able to print until the indicator stays on.
2LCD (Liquid Crystal Display)
Displays messages to help you set up
and operate your machine.
3Programming Keys:
Menu
Lets you access the Menu and
Programming mode.
Set
Stores a menu setting in the machine.
Also use for sending one fax to multiple
numbers.
(Left Arrow) (Right Arrow)
Moves the LCD cursor through text and
options.
Clear
Deletes entered data or backs up one
step in Menu table.
4One Touch Dial Keys
These 16 keys give you instant access to
previously stored phone numbers.
5Shift
To access memory locations 17 through
32 in the One Touch keys, hold down
the Shift key.
6Telephone Keys:
Hook
Lets you dial telephone and fax numbers
without lifting the handset.
Hold
Lets you place calls on hold.
Redial/Pause
Redials the last number called. Also
inserts a pause in autodial numbers.
7Search/Speed Dial
Lets you look up numbers stored in the
dialing memory. Also lets you dial
stored phone numbers by pressing # and
a three-digit (two-digit for FAX-4100)
number.
1
2
3
12
4
5
10
13 14 15 16
118 967
