2. Specifications
INPUT METHOD
Entry: 10-key system; Buffer memory 8 keys (2-key roll over)
Display (LED): Amount 8 digits (zero suppression); Department/PLU No.; No. of repeats
PRINTER
Receipt: 12 digits (Amount 10 digits, Symbol 2 digits)
(or journal) Automatic paper roll winding (journal)
Paper roll: 58 mm × 80 mm ∅ (Max.)
CALCULATIONS
Entry 8 digits; Registration 7 digits; Total 8 digits
CALCULATOR FUNCTION
8 digits; Arithmetic calculations; Percent calculations
Memory protection batteries:
The effective service life of the memory protection batteries (3 UM-3, R6P (SUM-3) or LR6 (AM-3) type batteries) is
approximately one year from installation into the machine.
Power source/Power consumption: See the rating plate.
Operating temperature: 0°C to 40°C (32°F to 104°F)
Humidity: 10 to 90%
Dimensions/Weight: 203 mm(H)× 330 mm(W)× 360 mm(D) with S drawer
4.1 kg with S drawer
250 mm(H)× 410 mm(W)× 450 mm(D) with M drawer
9 kg with M drawer
Specifications and design are subject to change without notice.
1. Troubleshooting
USEFUL INFORMATION
Part 4
Symptom/Problem
Most common causes
Solutions
1 E01 appears on the display.
2 E94 appears on the display.
3 No date or time on receipt.
Paper is not advancing enough.
4 Drawer opens up after ringing up only one
time.
5 Not clearing totals at end of day after taking
report.
6 Programming is lost whenever register is
unplugged or there is a power outage.
7 Register is inoperative.
Can’t get money out of drawer.
Changing modes without completing transaction.
Printer paper is jammed.
Printer is programmed as a journal.
Department is programmed as a single item dept.
Using X mode to take out reports.
Bad or no batteries.
No power.
Return mode switch to where it stops
buzzing and press p.
Remove jammed paper. Turn Mode
switch to OFF then turn to ON, or Turn
power OFF and then turn power ON.
Program printer to print receipts.
Program the dept. as a normal dept.
Use Z mode to take out reports.
Put in new batteries.
Pull lever underneath register at rear.
