Casio TK-6500 Cash Register User Manual



10
Getting Started
REG2 X1
REG1 Z1
OFF X2/Z2
RF
PGM
Install receipt/journal paper.
Loading journal paper
The same type of paper (45 mm × 83 mm i.d.) is used for receipts and journal. Load the new paper
before first operating the cash register or when red paper appears from the printer.
11
11
1
Use a mode key to set the
mode switch to REG1
position.
22
22
2
Open the printer cover
using the printer cover
key.
33
33
3
Cut off the leading end of
the paper so it is even.
44
44
4
Ensuring the paper is
being fed from the bottom
of the roll, lower the roll
into the space behind the
printer.
55
55
5
Drop the paper roll gently
and insert paper to the
paper inlet.
66
66
6
Press the j key until
about 20 cm to 30 cm of
paper is fed from the
printer.
77
77
7
Slide the leading end of
the paper into the groove
on the spindle of the take-
up reel and wind it onto
the reel two or three turns.
8.
