Send documentation comments to mdsfeedback-doc@cisco.com
2-8
Cisco MDS 9000 Family Fabric Manager Quick Configuration Guide
OL-7765-04
Chapter 2 Initial Switch Configuration
Using the Switch Setup Utility
Step 18 Enter on (on is the default) to configure the switch port trunk mode.
Configure default switchport trunk mode (on/off/auto) [on]: on
Step 19 Enter deny (deny is the default) to configure a default zone policy configuration.
Configure default zone policy (permit/deny) [deny]: deny
This step denies traffic flow for all members of the default zone.
Step 20 Enter yes (no is the default) to enable a full zone set distribution (refer to the Cisco MDS 9000 Family
CLI Quick Configuration Guide).
Enable full zoneset distribution (yes/no) [n]: yes
You see the new configuration. Review and edit the configuration that you have just entered.
Step 21 Enter no (no is the default) if you are satisfied with the configuration.
The following configuration will be applied:
switchname switch_name
interface mgmt0
ip address
mgmt_IP_address
subnetmask
mgmt0_ip_netmask
no shutdown
ip default-gateway
default_gateway
telnet server enable
no ssh server enable
no system default switchport shutdown
system default switchport trunk mode on
no zone default-zone permit vsan 1-4093
zoneset distribute full vsan 1-4093
Would you like to edit the configuration? (yes/no) [n]: no
Step 22 Enter yes (yes is the default) to use and save this configuration.
Use this configuration and save it? (yes/no) [y]: yes
Caution If you do not save the configuration at this point, your changes will not be updated the next
time that the switch is rebooted. Type yes to save the new configuration to ensure that the
kickstart and system images are also automatically configured.
