39
Printer Operation
7 Zebra
®
Emulation
Mode Settings
[Zebra
®
Emulation]
Top Menu Sub Menu Default Menu Remarks
Global – Config Set 1 Config Set 1 Sets the Config Set.
configuration Config Set 2
Config Set 3
Page Setup Print Speed 4 IPS 2 to 6 IPS [For CL-S621]
Printing speed setting.
(5 or 6 IPS only in Direct Thermal mode.)
(2 to 4 IPS with optional peeler.)
4 IPS 2 to 4 IPS [For CL-S631]
Printing speed setting.
Print Darkness 10 00 to 30 Print darkness setting
(printhead temperature)
Darkness Adjust 0 -10 to 10 Darkness command adjustment
Print Method Thermal transfer Thermal transfer Selecting thermal transfer (ribbon)
Direct thermal /direct thermal media
Ribbon Winding Outside Outside Selecting the ribbon winding direction.
Inside
Continuous Media 4.00 IN 0.25 to 32.00 IN Setting default length of continuous
Length 101.6mm 6.40 to 812.8mm media, if selected. ; the lower line is in metric
mode.
Vertical Position 0.00 IN -1.00 to 1.00 IN Print start position adjustment
0.0mm -25.4 to 25.4mm
Horizontal Shift 0.00 IN -1.00 to 1.00 IN Horizontal printing location adjustment
0.0mm -25.4 to 25.4mm
Vertical Image Shift 000dots -120 to 120 dots Adjust the off set value in vertical when
mapping data on a RAM.
Media Sensor See Through See Through Label sensor selection
Reflect
None
Small Media OFF ON Setting for small labels
Adjustment OFF
Small Media 1.00 IN 0.25 to 1.00 IN Setting length of small label media
Length 25.4mm 6.40 to 25.4mm
System Setup Sensor Level 1.5V 0.0V to 3.3V Setting the threshold of the sensor
Paper End Level 2.80V 0.01V to 3.00V Sets the paper end level.
Error Reporting On Printing On Printing Setting for error report.
Immediate
Buzzer Select ON ON Setting buzzer sounding conditions
OFF
Metric/Inch Inch Inch Setting the units used
mm
Max Media Length 10.00 IN 1.00 to 50.00 IN Setting the maximum label length
254.0mm 25.4 to 1270.0mm
Settings Lock Off On When on, prevents software commands from
Off changing the values set by the VuePrint menu
Keyboard Lock Off On Prevents the control panel from affecting
Off the printer's configuration. (User "lock-out")
Media Power Up Off On Selects whether or not to initiate media
Off measurement when the power in ON.
CI Lock Off On Activates/deactivates the CI command.
Off
