Printer Operation
38
Mode Settings
Top Menu Sub Menu Default Menu Remarks
Metric/Inch Inch Inch Sets the units.
[Metric/Inch Sel] mm
Max Media Length 10.00 inch 1.00 to 50.00 inch Sets the maximum media length.
[Max Media Len] 254.0 mm 25.4 to 1270.0 mm
Settings Lock Off On Prevents a command changing the set value.
Off
Keyboard Lock Off On Prevents a change by a key operation.
Off
Control Code STD STD Switches command mode of DMX mode.
ALT
Emulation Select DM4 DM4 Selects DataMax compatibility
[Emulation Sel] DMI DM4: DataMax 400
DPP DMI: DataMax IClass
DPP: DataMax Prodigy Plus
After Print AutoConfigure On On Automatically configures optional devices.
[Auto Config] Off On.... AutoConfigure enabled (Regardless of
whether Function Select is set, if a
peeler or cutter is installed, each mode
is set automatically.)
Off ... AutoConfigure disabled (A peeler of
cutter is installed, but to not operate
the peeler or cutter, turn it Off and the
operation is selected by
Function Select.)
Function Select Tear Off Selects the operation when the
[Function Sel] Tear AutoConfigure is set to Off. Designates the
Peel On* paper position based on each option. The
Cut On** operation of this device is enabled during
selection. At the same time, the parameters of
the f command of Prodigy Plus are emulated
for each optional device.
Cutter Action Backfeed Backfeed Sets the cutter action.
Through With the optional AutoConfigure On, printing
is executed only when the cutter is installed
or only when Cut is selected by Function
Select.
Backfeed is always set after cutting.
Through is set at the rear end of sheets 1 to
n-1 when the number of copies = n, and the
rear end of the final page of single sheet and
the copy is backfeed.
Paper Position 0.00 inch Peel/Cut/Tear Off Adjusts the stop position. It is based on the
0.00 mm 0.00 to 2.00 inch inch/millimeter setting. There are initial
0.0 to 50.8 mm values of the stop position for each device
Peel/Cut/Tear On set above, and later, relative values are set.
-1.00 to 1.00 inch
-25.4 to 25.4 mm
Repeat Key Disabled Label Set Switches the repeat printing method.
[REPEAT Key] Last One Label Set:
Disabled Repeats the number of copies.
Last One:
Last one is issued only for the final page.
In the case of a count, afterwards, only
last one is issued.
Disabled:
Repeat printing is disabled.
* Only when peeling option is mounted.
** Only when cutter is mounted.
