5.2 Manual Setting of Memory Switch
Memory switches can be set manually or by a command.
For manual setting, refer to the next page.
The function of each memory switch is shown in the following table. (The
white-on-black characters are factory setting.)
Switch No. Setting 0 (OFF) 1 (ON)
Memory SW1-1 Power ON Info Valid Not Send
SW1-2 Buffer Size 4k bytes 45 bytes
SW1-3 Busy Condition Full/Err Full
SW1-4 Receive Error Print “?” No Print
SW1-5 CR Mode Ignored LF
SW1-6 Reserved Fixed −
SW1-7 DSR Signal Invalid Valid
SW1-8 Reserved Fixed −
Memory SW2-1 Reserved − Fixed
SW2-2 Auto Cutter Invalid Valid
SW2-3 Spool Print Invalid Valid
SW2-4 Full Col Print LineFeed WaitData
SW2-5 Resume aft PE Next Top
SW2-6 Reserved − Fixed
SW2-7 Reserved Fixed −
SW2-8 PNE Sensor Valid * Invalid
Memory SW3-1 Resume Cttr Err Valid Invalid
SW3-2 Reserved Fixed −
SW3-3 Reserved − Fixed
SW3-4 Reserved Fixed −
SW3-5 Reserved Fixed −
SW3-6 Reserved Fixed −
SW3-7
CBM-270 Mode
Invalid Valid
SW3-8
Resume Open Err
Close Command
Memory SW4-1 Reserved Fixed −
SW4-2 Reserved Fixed −
SW4-3 Feed&Cut at TOF Invalid Valid
SW4-4 Reserved Fixed −
SW4-5 Reserved Fixed −
SW4-6 Reserved Fixed −
SW4-7 Reserved Fixed −
SW4-8 Partial Only Invalid Valid
*Factory option
