Chipset
Agere Systems SV92PL – Integrated PCI interface with 5-V tolerant
buffers and CardBus support
Dimensions
(L X H)
Complies with PCI low profile specifications-6.7 x 2.3 in (17.0 x 5.8 cm)
and supports high- and low-profile brackets
Connection
Single RJ-11 connector
Other Features
Digital line protection, call progress monitoring via on-board piezo
device, support for high profile and low profile brackets, PnP ID support
Safety
UL recognized to UL 1950, 3rd edition (U.S. and Canada); IEC 950
(TUV, NEMKO, DEMKO, SEMKO); CE Mark, EC 950 (TUV, NEMKO,
DEMKO, SEMKO, CE mark
EMC
FCC Part 15, IC ES003, EN 55022, 3rd edition, EN 55024, annex A, EN
61000-4-6, EN 61000-4-8
Telecom
FCC Part 68, IC-CS-03 (Canada); Worldwide PTT approvals
Not available in Korea or the Republic of South Africa.
Health
Bare PCB material compliant to 94V-0 or better (marked as such)
Other
PC 2001 compliant, PCI version 2.3, WHQL approved; ACPI compliant
QuickSpecs
HP Compaq dc7800 Business PC
Technical Specifications - Communications
DA - 12744 Worldwide QuickSpecs — Version 13 — 12.14.2007
Page 27
