Compaq dc7800 Personal Computer User Manual



Convertible Minitower
1.
(3) 5.25" external bays and (2) 3.5" internal bays
6.
Front I/O: (2) USB 2.0, headphone and microphone
2.
365-watt or 365-watt high efficiency 80 PLUS Active
Power Factor Correction (PFC) power supply
7.
(3) full-height PCI slots, (2) full-height PCI Express x1
slots, (1) full-height PCI Express x16 (ADD2/SDVO) slot
3.
Media Card Reader or other 5.25" device
8.
2-Button Optical Scroll Mouse (PS/2 or USB)
4.
Rear I/O: (6) USB 2.0, 1 standard serial port, (1) optional
serial port, (1) parallel port, (2) PS/2, (1) RJ-45, (1) VGA,
(1) audio in, (1) audio out
9.
HP Standard Keyboard (PS/2 or USB) or HP USB
Smartcard Keyboard
5.
Diskette drive or Media Card Reader
10.
Monitor (sold separately)
QuickSpecs
HP Compaq dc7800 Business PC
Overview
DA - 12744 Worldwide QuickSpecs — Version 13 — 12.14.2007
Page 3
