QuickSpecs
Compaq Evo Notebook N600c
DA-10886 North America — Version 18 — December 16, 2002 20
Technical Specifications
24X CD-ROM Drive
MultiBay Drive
Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.50 lb/0.22 kg
Applicable Disk
CD-ROM (Mode 1, 2 and 3), CD-XA ready (Mode 2, Form 1 and 2), CD-I ready
(Mode 2, Form 1 and 2), CD-R (read only), CD Plus, Photo CD (Single and Multi-
session), CD-Extra, Video CD, CD-WO (fixed packets only), CD-Bridge
Center Hole Diameter
15 mm
Disk Diameter
12 cm/8 cm
Disk Thickness
1.2 mm
Track Pitch
1.6 µm
Random < 150 ms
Access Times
(typical reads, including settling)
Full-Stroke < 300 ms
Audio Output Level
Line-out 0.7 Vrms
Cache Buffer
128 KB
Sustained (16X) 150 KB/s (sustained 1X)
Data Transfer Rate
(typical, including settling)
Variable 1500 to 3600 KB/s (10X to 24X)
Normal PIO Mode 4 (single
burst)
16.66 MB/s
Start-up Time
< 8 seconds
Stop Time
< 4 seconds
SuperDisk 2X LS-120 Drive
MultiBay Drive
Dimensions (H x W x D) 0.5 x 5.21 x 4.97 in/1.27 x 13.25 x 12.61 cm
Weight 0.6 lb/0.27 kg
Maximum Transfer Rate
From Disk 896 KB/s
Sustained: 375 to 900 KB/s
120 MB Physical Format
Number of Heads: 2
Bytes per Sector: 512
Sectors per Track: 51 to 92
Zones/Side: 55
Data Tracks per Side: 1736
Servo Tracks: 900
Sector Interleave: 1:1
Track–to–track: 20 ms
Access Times
(including setting)
Average: 70 ms
Latency Average: 41.67
Operating Conditions
Temperature: 41° to 131°F/5° to 55°C
Humidity: 10% to 80% RH
Operating System Support
Microsoft Windows 95, Windows NT 4.0
Option Kit Contents
LS-120 Drive, 17 mm MultiBay Adapter, Software, Documentation
NOTE: Drivers for the LS-120 Drive are standard in Windows 95/OSR2,
Windows NT 3.51/SP5, and Windows NT 4.0. Use the LS-120 Option
Support Diskette (included in option kit) with earlier releases of Windows
95 and NT 3.51.
