QuickSpecs
Compaq Evo Notebook N600c
DA-10886 North America — Version 18 — December 16, 2002 24
Technical Specifications
Bluetooth MultiPort Module
(continued)
Usage Models
Service Discovery (determine what Bluetooth devices are within range and
support authorization).
Synchronization:
PDAs to PCs
Portable to Desktop
File Transfer:
File and directory browsing and navigation on another Bluetooth device.
File copying
Object manipulation – including add, delete, create new folders etc.
Wireless link to Corporate LAN using several Bluetooth devices sharing the
same
Access Point:
Corporate email, network neighborhood, access to LAN applications, file
transfer, ftp, Internet browsing, etc, using TCP/IP
Wireless link to WAN thru cell phone
GSM/SMS, PCS, PHS, DECT, RAM, ARDIS, CDPD, etc.
Agnostic to WAN technology
Send/receive SMS messages
Wireless link to Printer
Adhoc peer to peer networking (two computers) or Personal Area Networking
(PAN) using NDIS (< 7 computers).
Adhoc Bluetooth Pico-networking (point to multi-point)
Object Push – Business card or appointment exchange
Transmit Power
< 20 dBM (Bluetooth Class 1)
Receive Sensitivity
Better than –70 dBM at 0.1% raw bit error rate
Link Topology
Point to Point, Multipoint Pico Nets up to 7 slaves
Security
Full support of Bluetooth Security Provisions
Network Architecture Models
Ad-hoc (Peer to Peer)
Infrastructure (Access Points Required)
Power Requirement
Peak < 1500 mW
Average < 500 mW
Standby < 250 mW
Power Management
Windows ACPI, and USB Bus Support
Keystrokes Fn+F2 Power On/Off control
Self configurable to optimize power conservation in all operating modes,
including Standby, Hold, Park, and Sniff
OS Support
Microsoft Windows XP Professional and Home Editions
Microsoft Windows 98/98SE
Microsoft Windows 2000
Microsoft Windows Millennium
Protocols Supported
TCP/IP
IPX/SPX
UDP
LED Activity
Solid Blue LED – On
LED Off – Power Off
Certifications
All necessary regulatory approvals for countries we support including
FCC (47 CFR) Part 15C, Section 15.247&15.249
ETS 300 328, ETS 300 826
Low Voltage Directive IEC950
UL, CSA, and CE Mark
