QuickSpecs
Compaq Evo Workstation W8000
DA-10847 World Wide — Version 19 — March 18, 2002 34
Technical Specifications
Dimensions (HxW) Approximately 6.5 x 3.8 x 0.6 in/16.51 x 9.65 x 1.52 cm
ATI Fire GL2 Graphics
Controller
Resolution
Maximum Colors
Supported
Maximum Refresh
Rate
Memory Dedicated to
Texture Support
640 x 480 16.7 M 240 Hz 28.4 MB
800 x 600 16.7 M 240 Hz 26.4 MB
1024 x 768 16.7 M 200 Hz 22.8 MB
1152 x 864 16.7 M 170 Hz 20.3 MB
1280 x 1024 16.7 M 150 Hz 16.6 MB
1600 x 1000 64 K 120 Hz 22.6 MB
1600 x 1000 16.7 M 120 Hz 13.3 MB
1600 x 1200 64 K 100 Hz 20.8 MB
1600 x 1200 16.7 M 100 Hz 9.5 MB
1600 x 1280 64 K 100 Hz 20 MB
1600 x 1280 16.7 M 100 Hz 8 MB
1920 x 1080 64 K 85 Hz 19.9 MB
1920 x 1080 16.7 M 85 Hz 7.7 MB
1920 x 1200 64 K 85 Hz 18.5 MB
1920 x 1200 16.7 M 85 Hz 5 MB
Form Factor ATX
3D/2D Controller IBM RC1000 Rasterizer Chip
VGA Controller IBM RC1000 Rasterizer Chip
Bus Type AGP 2X/4X Version 2 compliant including side band signaling support
RAMDAC 300 MHz IBM RC1000
Memory Type DDR SGRAM
Memory Amount 64 MB DDR SGRAM unified frame buffer, Z-buffer and Texture storage
Memory Speed 120 MHz
Controller Clock Speed 120 MHz
Color Planes 32 bit, True Color
Overlay Planes 8-bit
Stencil Planes 8-bit
Alpha Planes 8-bit
Z-buffer 24-bit
Video Engine support YUV (4:2:2, 4:2:0) conversion, point and bilinear scaling
Mini-Din Stereo Interface support StereoGrpahics CrystalEyes shutter glasses
Monitor 15-pin D-type analog
Flat Panel Interface DVI-D digital (supported resolutions up to 1280x1024 )
Video Timings compliance VESA DMT 1.0 and VESA GTF 1.0 specifications
Total bits/pixel 117
Maximum Vertical Refresh Rate 100 Hz / 120 Hz when Quad Buffer Stereo is enabled
Maximum Pixel Clock 300 MHz
Operating Systems
Microsoft
Windows 2000 Professional, Windows NT 4.0, Windows XP
Professional
Note: All drivers can be found on the Compaq web site at:
www.compaq.com/support/files/workstations/us/index.html.
