-13-
INSTALLATION
This TV provides one group of AV ,one S-Video,one group of YPbPr for convenient connection
to VCR,DVD or other video equipment. Please refer to the owner s manual of the equipment to
be connected as well.
You can use the input terminals on TV set rear as follows.
It can be connected to the following appliances: VCR, multi disc player, DVD, camcorder,
video game or stereo system, etc.....
YPbPr can support these video fomats:480i,576i,480p,576p,720p,1080p,1080i.
To audio
outputswith
terminal
VIDEO EQUIPMENT
VIDEO EQUIPMENT withYPbPr
To audio outputs
with S-video
terminal
VIDEO EQUIPMENT
To S-VIDEO
output
Yellow (video)
White(audio L)
Red(audio R or Pr)
Y
W
R
Y W R
R
W
Y
W R
W R
output
To video
G
B
R
G
B
R
Blue(Pb)
Green(Y)
B
G
ANT
AV
S-VIDEO
L
R
AUDIO
INPUT
YPbPr
INPUT
Y
Pb
Pr
AUDIO
VGAINPUT
VGAINPUT
100-240V~ 50/60Hz
AC-INPUT
HDMI
ANT
AV
S-VIDEO
L
R
AUDIO
INPUT
YPbPr
INPUT
Y
Pb
Pr
AUDIO
VGAINPUT
VGAINPUT
100-240V~ 50/60Hz
AC-INPUT
HDMI
AV EQUIPMENT
