CY8C23433, CY8C23533
Document Number: 001-44369 Rev. *B Page 19 of 37
DC Low Power Comparator Specifications
The following table lists the guaranteed maximum and minimum specifications for the voltage and temperature ranges: 4.75V to 5.25V
and -40°C ≤ T
A
≤ 85°C, or 3.0V to 3.6V and -40°C ≤ T
A
≤ 85°C, respectively. Typical parameters apply to 5V and 3.3V at 25°C and
are for design guidance only.
Table 14. 3.3V DC Operational Amplifier Specifications
Symbol Description Min Typ Max Units Notes
V
OSOA
Input Offset Voltage (absolute value)
Power = Low, Opamp Bias = High
Power = Medium, Opamp Bias = High
High Power is 5 Volts Only
–
–
1.65
1.32
10
8
mV
mV
TCV
OSOA
Average Input Offset Voltage Drift – 7.0 35.0 μV/°C
I
EBOA
Input Leakage Current (Port 0 Analog Pins) – 20 – pA Gross tested to 1 μA.
C
INOA
Input Capacitance (Port 0 Analog Pins) – 4.5 9.5 pF Package and pin dependent.
Temp = 25°C
V
CMOA
Common Mode Voltage Range 0.2 – Vdd - 0.2 V The common-mode input
voltage range is measured
through an analog output
buffer. The specification
includes the limitations
imposed by the character-
istics of the analog output
buffer.
G
OLOA
Open Loop Gain
Power = Low, Opamp Bias = Low
Power = Medium, Opamp Bias = Low
Power = High, Opamp Bias = Low
60
60
80
– – dB Specification is applicable at
high power. For all other bias
modes (except high power,
high opamp bias), minimum is
60 dB.
V
OHIGHOA
High Output Voltage Swing (internal signals)
Power = Low, Opamp Bias = Low
Power = Medium, Opamp Bias = Low
Power = High is 5V only
Vdd - 0.2
Vdd - 0.2
Vdd - 0.2
–
–
–
–
–
–
V
V
V
V
OLOWOA
Low Output Voltage Swing (internal signals)
Power = Low, Opamp Bias = Low
Power = Medium, Opamp Bias = Low
Power = High, Opamp Bias = Low
–
–
–
–
–
–
0.2
0.2
0.2
V
V
V
I
SOA
Supply Current (including associated AGND buffer)
Power = Low, Opamp Bias = High
Power = Medium, Opamp Bias = Low
Power = Medium, Opamp Bias = High
Power = High, Opamp Bias = Low
Power = High, Opamp Bias = High
–
–
–
–
–
300
600
1200
2400
4600
400
800
1600
3200
6400
μA
μA
μA
μA
μA
PSRR
OA
Supply Voltage Rejection Ratio 52 80 – dB Vss ≤ VIN ≤ (Vdd - 2.25) or
(Vdd - 1.25V) ≤ VIN ≤ Vdd
Table 15. DC Low Power Comparator Specifications
Symbol Description Min Typ Max Units
V
REFLPC
Low power comparator (LPC) reference voltage
range
0.2 – Vdd - 1 V
I
SLPC
LPC supply current – 10 40 μA
V
OSLPC
LPC voltage offset – 2.5 30 mV
