Example 4.7. Creating an OSPF Router Process
On the first firewall involved in the OSPF AS, create an OSPF Router Process.
Web Interface
1. Go to Routing > OSPF > Add > OSPF Routing Process
2. Specify a suitable name for the process, for example as_0
3. Click OK
This should be repeated for all the NetDefend Firewalls that will be part of the OSPF AS.
Example 4.8. Add an OSPF Area
Now add an OSPF Area object to the OSPF Router Process object as_0. The area will be the backbone area and
will have the ID 0.0.0.0.
Web Interface
1. Go to Routing > OSPF
2. Select the routing process as_0
3. Select Add > OSPF Area
4. For the area properties:
• Enter a suitable name. For example, area_0
• Specify the Area ID as 0.0.0.0
5. Click OK
This should be repeated for all the NetDefend Firewalls that will be part of the OSPF area.
Example 4.9. Add OSPF Interface Objects
Now add OSPF Interface objects for each physical interface that is to be part of the OSPF area area_0.
Web Interface
1. Go to Routing > OSPF > as_0 > area_0 > OSPF Interfaces
2. Select Add > OSPF Interface
3. Select the Interface. For example, lan
4. Click OK
Just selecting the Interface means that the Network defaults to the network bound to that interface. In this case
lannet.
This should be repeated for all the interfaces on this NetDefend Firewall that will be part of the OSPF area and
then repeated for all the other firewalls.
Example 4.10. Import Routes from an OSPF AS into the Main Routing Table
